So the code is pretty straight forward, I have a PermissionChecker whose job is to use the IModuleDisabler to turn off certain modules depending upon the user permissions. Pretty straightforward implementation.
Now that the solution is fleshed out, it’s time to write some tests around this. When it comes to testing classes that have dependencies on non-trivial classes, I use NSubstitute, a mocking tool, to create mock versions of those dependencies. In this case, NSubstitute allows me to test how the IModuleDisabler is being used by the PermissionsChecker.
For example, let’s say that I wanted to test how the PermissionChecker interacts with the IModuleDisabler when the user has a partial access, I’d write a test that looks like the following:
In the above test, our assertion step is to check if the mockDisabler received a single call to the DisableReportModule. If it didn’t receive a call, then the test fails. We can write similar tests for the different modules that should be disabled for the partial rights permission and follow a similar pattern for the full rights permission.
However, things get a bit more interesting when we’re testing what happens if the user is an admin. If we follow the same pattern, we’d end up with a test that looks like this:
The issue arises when we add a new module to be disabled which forces the IModuleDisabler to implement a new method. In that case, you need to remember to update this test to also check that the new method wasn’t being called. If you forget, this test would still pass, but it’d pass for the wrong reason.
To help illustrate, let’s say that another method, DisableImportModule, has been added to the IModuleDisabler interface. In addition, we also need to make sure that this is called when users have partial access, but should not be called for users who are admins or users who have full access.
To fulfill those requirements, we modify the PermissionChecker as so:
At this point, we’d write another test for when the a user has partial access, the import module should be disabled. However, it’s very unlikely that we’d remember to update the test for the admin. Remember, for the admin, we’re checking that it received no calls to any disable methods and the way we’re doing that is by checking each method individually.
[Test]publicvoidAnd_the_user_has_admin_permissions_then_the_disabler_is_not_used(){// ArrangevarpermissionChecker=newPermissionChecker();varmockDisabler=Substitute.For();varuser=newUser{IsAdmin=true};// ActpermissionChecker.CheckPermissions(mockDisabler,user);// AssertmockDisabler.DidNotReceive().DisableSystemAdminModule();mockDisabler.DidNotReceive().DisableReportModule();mockDisabler.DidNotReceive().DisableUserManagementModule();// Need to add check for DidNotReceive().DisableImportModule();}
There’s got to be a better way. After some digging around, I found that any NSubstitute mock, has a ReceivedCalls method that returns all calls that the mock received. With this new knowledge, we can refactor the previous test with the following:
This solution is much better because if we add more modules, this test is still checking to make sure that admin users do not have any modules disabled.
When using a NSubstitute mock and you need to make sure that it received no calls to any methods or properties, you can using NSubstitute’s ReceivedCalls in conjunction with CollectionAssert.IsEmpty to ensure that the substitute was not called.
There is nothing new in the world except the history you do not know.
– Harry S. Truman
The more experience I gain problem solving, the more this holds true. For this post, I’m going to first discuss the problem that I was trying to solve. Next, I’ll show what my first solution was, followed by the shortcomings of this solution. Thirdly, we’ll iterate over a better solution to the problem. This in turn, will provide the motivation for what the Chain of Responsibility is and how to implement. Finally, I’ll wrap up with what the benefits were of using this design. .
As part of the process of installing our software, there are scripts that will update the database from it’s current version to the latest version. As it stands, it needs to be able to upgrade a database from any version to the current version.
The first thing that comes to me is that I need to apply database scripts in a sequential way. For example, if the database’s current version is 1.0 and the latest version is 3.0, it would need to apply the script to upgrade the database from 1.0 to 2.0 and then apply the script to upgrade the database from 2.0 to 3.0.
For the first implementation, there were only two versions, 1.0 and 2.0. Since I didn’t want to build in a lot of functionality if it wasn’t needed yet, I created a helper method that returns the correct updater for a given version. In the below code, if the version does not exist, I assume the database does not exist and return the class that will create the database. Otherwise if the version is 1.0, I return a class that is responsible for the upgrading a database from 1.0 to 2.0. If the version is 2.0, I return a class that doesn’t do anything (i.e. there’s no upgrades to be done).
publicIDatabaseUpdaterGetDatabaseUpdater(stringversion){if(string.IsNullOrWhiteSpace(version))returnnewDatabaseCreator();if(version=="1.0")returnnewDatabase100To200Updater();if(version=="2.0")returnnewCurrentVersionUpdater();thrownewArgumentException("The version "+version+" is not supported for database upgrades.");}
This solution worked well when there only three possible actions (create a new database, apply the single script, or do nothing). However, we are now going to be shipping version 3.0 and there will need to be a new class that is responsible for upgrading the 2.0 to 3.0. In order to add this functionality, I’d have to do the following:
Create the Database200To300Updater class that contained the logic for updating the database from 2.0 to 3.0.
Modify the Database100To200Updater class to also use the Database200To300Updater in order to perform the next part of the upgrade.
Add additional logic to the above method so that if the database is 2.0 to return the Database200To300Updater class.
After making the modifications, the method now looks like:
publicIDatabaseUpdaterGetDatabaseUpdater(stringversion){if(string.IsNullOrWhiteSpace(version))returnnewDatabaseCreator();if(version=="1.0")returnnewDatabase100To200Updater(newDatabase200To300Updater());if(version=="2.0")returnnewDatabase200To300Updater();if(version=="3.0")returnnewCurrentVersionUpdater();thrownewArgumentException("The version "+version+" is not supported for database upgrades.");}
So far, so good, we now have the logic to be able to apply scripts in order, however, now that we’ve added version 3.0, I start to wonder what I would do if we added more versions? After some thought, it would look identical to the previous steps (see below for what would happen if we added version 4.0).
publicIDatabaseUpdaterGetDatabaseUpdater(stringversion){if(string.IsNullOrWhiteSpace(version))returnnewDatabaseCreator();if(version=="1.0")returnnewDatabase100To200Updater(newDatabase200To300Updater(newDatabase300To400Updater()));if(version=="2.0")returnnewDatabase200To300Updater(newDatabase300To400Updater());if(version=="3.0")returnnewDatabase300To400Updater();if(version=="4.0")returnnewCurrentVersionUpdater();thrownewArgumentException("The version "+version+" is not supported for database upgrades.");}
If we create some variables to hold onto these classes, and reorder the if statements, we can write this helper method as:
publicIDatabaseUpdaterGetDatabaseUpdater(stringversion){if(string.IsNullOrWhiteSpace(version))returnnewDatabaseCreator();if(version=="4.0")returnnewCurrentVersionUpdater();vardatabase300Updater=newDatabase300To400Updater();vardatabase200Updater=newDatabase200To300Updater(database300To400Updater);vardatabase100Updater=newDatabase100To200Updater(database200To300Updater);if(version=="1.0")returndatabase100Updater;if(version=="2.0")returnnewdatabase200Updater;if(version=="3.0")returnnewdatabase300Updater;thrownewArgumentException("The version "+version+" is not supported for database upgrades.");}
What I find interesting in this design is that I’ve now chained these updater classes together so that if the version 1.0 is returned, it will also use the 2.0 updater, which in turn calls the 3.0 updater. It was at this point, that I remembered a design pattern that followed this structure.
In this design pattern, you essentially have Handlers (in my case updaters) that check to see if they can handle the request. If so, they do and that stops the chain. However, if they can’t handle the request, they pass it to their Successor (which was also a Handler) to handle the request. The design pattern I was thinking about is the Chain of Responsibility pattern.
In order to implement this pattern, you need to have an IHandler interface that exposes a Handle method and either a method or property to set the Successor. The method is the action to take (in our case Update) and the Successor represents the next Handler in the chain if the request could not be handled. The second component is referred to as ConcreteHandlers and they are just the implementors of the interface. One way to implement this is like the following:
publicinterfaceIHandler{IHandlerSuccessor{get;set;}voidUpdate(intversion);}publicclassConcreteHandlerA:IHandler{publicIHandlerSuccessor{get;set;}publicvoidUpdate(intversion){if(CanTheRequestBeHandled){// handle the request}else{Successor.Update(version);}}}
The main difference between the pattern and what I need is that instead of doing if (canHandle)/else call Successor, what I’m really looking for is to run the upgrade script if the version we’re upgrading to is higher than our current version and then always call the successor. Given this change, here’s what that new implementation looks like:
publicclassConcreteHandlerA:IHandler{publicSuccessor{get;set;}publicvoidUpdate(intversion){if(CanTheRequestBeHandled){// handle the request}Successor.Update(version);}}
Now that I know the pattern to use and how it works, I need to update the IDatabaseUpdater interface to follow the IHandler interface. Next, I will need to modify the concrete handlers to use the new interface correctly.
Second, we will need to update our concrete handlers to implement the interface correctly and to update their UpdateMethod to follow the design. In my case, the concrete handlers perform similar logic, so one of the classes is used for an example.
publicclassDatabase100To200Updater:IDatabaseUpdater{privateDatabase200To300Updater_successor;publicDatabase100To200Updater(Database200To300Updatersuccessor){if(successor==null)thrownewArgumentNullException("successor");_successor=successor;}publicvoidUpdate(){Console.WriteLine("Updating the database to version 2.0");_successor.Update();}}
publicclassDatabase100To200Updater:IDatabaseUpdateHandler{publicvoidUpdate(intversion){if(version>=2)Console.WriteLine("Updating the database to version 2.0");if(Successor!=null)Successor.Update(version);}publicIDatabaseUpdateHandlerSuccessor{get;set;}}
What I really like about the chain of responsibility pattern is that I was able to connect my upgrade classes together in a consistent fashion. Another reason why I like this pattern is that it forces me to have the logic to determine whether I should run the update or not inside the individual classes instead of the helper method. This produces more readable code which then lends itself to easier maintainability.
During this past week, I was working with our intern and showing him some cool debugging tricks when I came across a massive method. I gave him 30 seconds to look at it and tell me what he thought the method was doing. After a while, he was able to figure it out, but the fact that it wasn’t easy discernible was enough to give pause.
The lesson here is that if you can’t determine what the method is doing easily, then it’s probably doing way too much (violating the Single Responsibility Principle) and needs to be broken into more easily readable pieces.
To demonstrate what I mean, I wrote a program that inserts Messages into a database. A Message contains a description, the number (for identification when troubleshooting) and the module. We would have issues where different messages would have the same number which would cause confusion when troubleshooting errors.
In the program I wrote, the user provides the message and what module the message belongs to and the program automatically generates the message number and inserts the message into the database.
For brevity’s sake, shown below is the logic for determining what the next message number should be.
publicintGetNextAlertAndErrorModuleNumber(stringmodule){if(String.IsNullOrEmpty(module))thrownewArgumentException("module cannot be null or empty");if(_connection==null)_connection=CreateConnection();varresults=newList<int>();_connection.Open();varcmd=newSqlCommand("dbo.GetAlertData",_connection);cmd.CommandType=CommandType.StoredProcedure;varreader=cmd.ExecuteReader();while(reader.Read()){if(!reader["ALERT_ID_NUMBER"].ToString().Contains(module))continue;varpieces=reader["ALERT_ID_NUMBER"].ToString().Split(‘‘);results.Add(Int32.Parse(pieces[1]));}if(reader!=null)reader.Close();cmd=newSqlCommand("dbo.GetErrorData";,_connection);cmd.CommandType=CommandType.StoredProcedure;reader=cmd.ExecuteReader();while(reader.Read()){if(!reader["ERROR_ID_NUMBER"].ToString().Contains(module))continue;varpieces=reader["ERROR_ID_NUMBER"].ToString().Split(‘‘);results.Add(Int32.Parse(pieces[1]));}if(reader!=null)reader.Close();if(_connection!=null)_connection.Close();returnresults.Max()+1;}
The method itself isn’t complex, just calling some stored procedures, parsing the output and adding the number to a list. However, it’s not abundantly clear what the purpose of the calling the stored procedures.
First, it looks like we’re reading the alerts error numbers from a stored procedure call, why don’t we extract that logic out to a helper method and have the public method call the helper?
By doing this, we fix two issues at once. First, we’ve given a name to the process of reading the alerts which in turns allows us to quickly understand what the public method should be doing (i.e. improved readability).
Second, it allows us for easier debugging because we now have smaller components. For example, let’s say that we were getting the wrong value. In the first implementation, we would have to put breakpoints in different areas trying to determine which part was broken. However, in the new form, we can check to see if ReadAlerts is behaving correctly. If it isn’t, we now know the bug has to be in that method, otherwise, it’s in the rest.
For the next step, you may have noticed that we can repeat the same refactoring trick again, except this time, we can extract the logic for reading the errors into a helper method.
publicintGetNextAlertAndErrorModuleNumber(stringmodule){if(String.IsNullOrEmpty(module))thrownewArgumentException("module cannot be null or empty");if(_connection==null)_connection=CreateConnection();_connection.Open();varresults=newList<int>();results.AddRange(ReadAlerts(module.ToUpper()));results.AddRange(ReadErrors(module.ToUpper()));if(_connection!=null)_connection.Close();returnresults.Max()+1;}privateList<int>ReadAlerts(stringmodule){varresults=newList<int>();varcmd=newSqlCommand("dbo.GetAlertData",_connection);cmd.CommandType=CommandType.StoredProcedure;varreader=cmd.ExecuteReader();while(reader.Read()){if(!reader["ALERT_ID_NUMBER"].ToString().Contains(module))continue;varpieces=reader["ALERT_ID_NUMBER"].ToString().Split(‘‘);results.Add(Int32.Parse(pieces[1]));}if(reader!=null)reader.Close();returnresults;}privateList<int>ReadErrors(stringmodule){varresults=newList<int>();varcmd=newSqlCommand("dbo.GetErrorData",_connection);cmd.CommandType=CommandType.StoredProcedure;varreader=cmd.ExecuteReader();while(reader.Read()){if(!reader["ERROR_ID_NUMBER"].ToString().Contains(module))continue;varpieces=reader["ERROR_ID_NUMBER"].ToString().Split(‘‘);results.Add(Int32.Parse(pieces[1]));}if(reader!=null)reader.Close();returnresults;}
After the changes, anyone who looks at the public API can easily see that it’s reading from both Alerts and Errors. This is really powerful because now you can communicate with non-technical people about requirements and what the code is doing.
Let’s say that in the future, the requirements change and this conversation plays out:
Alice (QA, finding an error) – Hey Bob, I was running one of our test plans and it looks like that we’re getting the wrong message number if we’re trying to add a new message and there are warning messages in the database. We are including the warning table when figuring that out, right?
Bob (Engineer, finding the root cause) – Hey you’re right, it looks like we’re only using the alerts and error tables when calculating the next number. Why don’t we write up a ticket for that and get a fix in?
The key point is that no matter how large a method is, there always have to be steps being performed in some order (by definition of an algorithm) and this is the key to refactoring larger methods into more maintainable pieces of code. The trick is determining what those steps are and making decisions on whether to make helper methods or helper classes.
If those steps become complicated, then they should be broken out into helper methods. As time progresses and those helper methods start to become more complicated, then those helper methods should in turn become classes of their own.
publicIStrategyGetStrategy(Projectproject,boolisAffected){vartype=project.Type;if(type==ProjectType.A&&isAffected)returnnewProjectAIsAffectedStrategy();if(type==ProjectType.B)returnnewProjectBStrategy();// Similar if statements}
At first glance, it looks pretty good. Logic was sound and it seemed to be returning a class implementing an interface similar to what we would expect for the Factory pattern. However, there’s a slight problem, can you spot it?
The issue is with the first parameter, Project. The method takes a Project, however, we’re only really depending on the Project’s Type property.
publicIStrategyGetStrategy(Projectproject,boolisAffected){vartype=project.Type;if(type==ProjectType.A&&isAffected)returnnewProjectAIsAffectedStrategy();if(type==ProjectType.B)returnnewProjectBStrategy();// Similar if statements}
So why don’t we get rid of the dependency on the Project and instead replace it with the dependency on the ProjectType instead?
publicIStrategyGetStrategy(ProjectTypetype,boolisAffected){if(type==ProjectType.A&&isAffected)returnnewProjectAIsAffectedStrategy();if(type==ProjectType.B)returnnewProjectBStrategy();// Similar if statements}
Instinctual, I knew this was the right call, but I couldn’t remember why I knew it was a good choice. After some digging, I remembered that this is a Law of Demeter violation, or better known as the Principle of Least Knowledge violation.
In general, this principle states that a method should have the least amount of information it needs to do it’s job. Other classic violations of this principle is when you use a class’s internals internals. For example,
One of the reasons that I really like the Law of Demeter is that if you follow it, you create easier to test methods. Don’t believe me? Which is easier to create, the Project class (which may have many dependencies that would need to be stubbed) or the ProjectType enum (which by definition has zero dependencies)?
Another reason that following the Law of Demeter is good practice is that it forces your code to be explicit about what dependencies are required. For example, in the first implementation, the caller knew that the method needed a Project, but had no clue on how much of the Project it needed (does it need all of the properties set? Does it need further setup besides basic instantiation?). However, with the refactored version, now it’s much clearer that the method has a looser dependency on not Project, but just the ProjectType.
