## Mars Rover – Implementing Rover – Turn Right

Welcome to the ninth installment of Learning Through Example – Mars Rover! In this post, we’re going to start driving out the functionality for the Rover and the business rules for turning right! First, we’ll take a look at the requirements to make sure we have an idea of what’s needed. From there, we’ll start implementing the requirements. By the end of this post, we’ll have a Rover that can do perform all of the commands!

### Turning in Place By Turning Right

If we look back at the original requirements for turning right, we find this single line as the requirement

When the rover is told to turn right, it will rotate 90 degrees to the right, but not change its location

Given this requirement, we’re able to double-check with our Subject Matter Expert that the `Rover` is essentially rotating in place which yields the following requirements.

• Given the `Rover` is facing `North`, when it turns right, then the `Rover` should be facing `East` at the same `Coordinate`
• Given the `Rover` is facing `East`, when it turns right, then the `Rover` should be facing `South` at the same `Coordinate`
• Given the `Rover` is facing `South`, when it turns right, then the `Rover` should be facing `West` at the same `Coordinate`
• Given the `Rover` is facing `West`, when it turns right, then the `Rover` should be facing `North` at the same `Coordinate`

So far, the requirements are very similar to when we were implementing `TurnLeft`, so let’s see if we can leverage the same setup!

#### Red/Green/Refactor For Rover Facing North

Given what we learned when we were implementing the rules for `TurnLeft`, I’m going to go ahead and copy the test and add the single case for when `Rover` faces `North`

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] [TestCase(Direction.North, Direction.East, TestName = "AndFacingNorthThenTheRoverFacesEast")] public void RoverTurningRight(Direction start, Direction expected) { var rover = new Rover { Orientation = start }; var initialLocation = rover.Location; rover.TurnRight(); Assert.AreEqual(expected, rover.Orientation); Assert.AreEqual(initialLocation, rover.Location); } ``````

Since `TurnRight` doesn’t exist, this test will fail so let’s go ahead and write enough code to make it pass. For the implementation, I’m going to go ahead and take advantage of the pattern that we found last time, yielding the following

 ```1 2 3 4 5 6 7 8 9``` ``````public void TurnRight() { Action ifNorth = () => Orientation = Direction.East; Action ifSouth = () => {}; Action ifEast = () => {}; Action ifWest = () => {}; Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

One thing to note is to take a look at how we defined `ifSouth`, `ifEast`, and `ifWest`. Since we’re still wanting to implement one requirement at a time, I’ve defined them to do nothing so that if `Execute` is called, nothing will happen. Alternatively, I could have defined them to throw an exception, but I believe that’s a bit much since we’ll be implementing the functionality soon!

With that implementation, our test passes, so it’s time to go on to the next requirement!

#### Rapid Test Creation with TestCase

With a parameterized unit test in place, adding a new test is as simple as adding a new `TestCase` attribute.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13``` ``````[Test] [TestCase(Direction.North, Direction.East, TestName = "AndFacingNorthThenTheRoverFacesEast")] [TestCase(Direction.East, Direction.South, TestName = "AndFacingEastThenTheRoverFacesSouth")] public void RoverTurningRight(Direction start, Direction expected) { var rover = new Rover { Orientation = start }; var initialLocation = rover.Location; rover.TurnRight(); Assert.AreEqual(expected, rover.Orientation); Assert.AreEqual(initialLocation, rover.Location); } ``````

And updating `ifEast` action in the `TurnRight` method

 ```1 2 3 4 5 6 7 8 9``` ``````public void TurnRight() { Action ifNorth = () => Orientation = Direction.East; Action ifSouth = () => {}; Action ifEast = () => Orientation = Direction.South; Action ifWest = () => {}; Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

Now that we’ve proven how easy it is to make this change, let’s go ahead and knock out the final two test cases

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] [TestCase(Direction.North, Direction.East, TestName = "AndFacingNorthThenTheRoverFacesEast")] [TestCase(Direction.East, Direction.South, TestName = "AndFacingEastThenTheRoverFacesSouth")] [TestCase(Direction.South, Direction.West, TestName = "AndFacingSouthThenTheRoverFacesWest")] [TestCase(Direction.West, Direction.North, TestName = "AndFacingWestThenTheRoverFacesNorth")] public void RoverTurningRight(Direction start, Direction expected) { var rover = new Rover { Orientation = start }; var initialLocation = rover.Location; rover.TurnRight(); Assert.AreEqual(expected, rover.Orientation); Assert.AreEqual(initialLocation, rover.Location); } ``````

And implement the code to make those cases pass

 ```1 2 3 4 5 6 7 8 9``` ``````public void TurnRight() { Action ifNorth = () => Orientation = Direction.East; Action ifSouth = () => Orientation = Direction.West; Action ifEast = () => Orientation = Direction.South; Action ifWest = () => Orientation = Direction.North; Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

Goodness, that was a pretty quick implementation of `TurnRight`! Thanks to our previous refactoring in `Rover` and leveraging parameterized testing, we were able to implement this new feature with a minimal amount of code and the code we did write was focused on the new functionality, not boilerplate.

With that being said, here’s our final version of `Rover`!

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62``` ``````public class Rover { public Direction Orientation { get; set; } public Coordinate Location { get; set; } public Rover() { Orientation = Direction.North; Location = new Coordinate(); } public void MoveForward() { Action ifNorth = () => Location=Location.AdjustYBy(1); Action ifSouth = () => Location=Location.AdjustYBy(-1); Action ifEast = () => Location=Location.AdjustXBy(1); Action ifWest = () => Location=Location.AdjustXBy(-1); Execute(ifNorth, ifSouth, ifEast, ifWest); } public void MoveBackward() { Action ifNorth = () => Location=Location.AdjustYBy(-1); Action ifSouth = () => Location=Location.AdjustYBy(1); Action ifEast = () => Location=Location.AdjustXBy(-1); Action ifWest = () => Location=Location.AdjustXBy(1); Execute(ifNorth, ifSouth, ifEast, ifWest); } public void TurnLeft() { Action ifNorth = () => Orientation = Direction.West; Action ifWest = () => Orientation = Direction.South; Action ifSouth = () => Orientation = Direction.East; Action ifEast = () => Orientation = Direction.North; Execute(ifNorth, ifSouth, ifEast, ifWest); } public void TurnRight() { Action ifNorth = () => Orientation = Direction.East; Action ifEast = () => Orientation = Direction.South; Action ifSouth = () => Orientation = Direction.West; Action ifWest = () => Orientation = Direction.North; Execute(ifNorth, ifSouth, ifEast, ifWest); } private void Execute(Action ifNorth, Action ifSouth, Action ifEast, Action ifWest) { switch(Orientation) { case Direction.North: ifNorth(); break; case Direction.South: ifSouth(); break; case Direction.East: ifEast(); break; case Direction.West: ifWest(); break; } } } ``````

### Wrapping Up

With the completion of `TurnRight`, the Rover has finally been implemented with all required pieces of functionality. Through this process, we learned how to write good unit tests, how to refactor unit tests to use parameterized unit testing, and reducing repetition through a SOLID refactor of `if/else` all of which culminating in `TurnRight` being a simple piece of functionality to include. In the next post, we will start working on implementing our logger!

## Mars Rover – Implementing Rover – Refactoring Rover

Welcome to the eighth installment of Learning Through Example – Mars Rover! In this post, we’re going to examine the `Rover` class and see what refactoring we can do based on some patterns we’re seeing with `MoveForward`, `MoveBackward`, and `TurnLeft`. After looking at the characteristics, we’ll explore a couple of different approaches with their pros and cons. Finally, we’ll make the refactor, using our test suite to make sure we didn’t regress in functionality.

### What’s The Problem

If we look at the definition for `Rover`, it becomes clear that we have some major code duplication going on with regards to its `MoveForward`, `MoveBackward`, and `TurnLeft` methods.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} public Rover() { Orientation = Direction.North; Location = new Coordinate {X=0, Y=0}; } public void MoveForward() { if (Orientation == Direction.North) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(-1); } if (Orientation == Direction.East) { Location = Location.AdjustXBy(1); } if (Orientation == Direction.West) { Location = Location.AdustXBy(-1); } } public void MoveBackward() { if (Orientation == Direction.North) { Location = Location.AdjustYBy(-1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.East) { Location = Location.AdjustXBy(-1); } if (Orientation == Direction.West) { Location = Location.AdjustXBy(1); } } public void TurnLeft() { if (Orientation == Direction.North) { Orientation = Direction.West; } else if (Orientation == Direction.West) { Orientation = Direction.South; } else if (Orientation == Direction.South) { Orientation = Direction.East; } else if (Orientation == Direction.East) { Orientation = Direction.North; } } } ``````

Based on the implementations, it seems like knowing what `Direction` the `Rover` is facing is a key rule to determine what update the `Rover` needs to do. The big pain point with this block of statements is that if we added a new `Direction` (like NorthEast), then we’d have to update these statements in multiple places even though all of these instances are referring to the same concept (i.e is the `Rover` facing this `Direction`). The other, more nuanced issue is that if we added a new `Direction`, there’s nothing forcing us to update all of these places because of our use of `if/else`.

### How To Resolve?

From what we’re seeing, the primary issue are the duplicated `if/else` statements, so one of our primary design goals should be to have that logic in one place (instead of three different places). From there, we’d also like to have a way for the compiler to force us to handle the different `Directions` that the `Rover` is facing.

#### Isolating the if/else

In order to isolate the `if/else`, let’s go ahead and extract the logic to a new private method

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````private xxx Execute(xxxx) { if (Orientation == Direction.North) { // } else if (Orientation == Direction.South) { // } else if (Orientation == Direction.East) { // } else if (Orientation == Direction.West) { // } } ``````

We’ve now got the `if/else` isolated, but there are some questions on what the return type of this method should be or what parameters it will take. In order to answer those questions, let’s take a look at a couple of different approaches.

#### Using a Functional Approach

Now that we have a method that can operate given the `Rover`'s `Orientation`, one approach we could do is to modify this method to take in an Action for every possible `Orientation`. Then based on the `Orientation`, the appropriate `Action` is called.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````private void Execute(Action ifNorth, Action ifSouth, Action ifEast, Action ifWest) { if (Orientation == Direction.North) { ifNorth(); } else if (Orientation == Direction.South) { ifSouth(); } else if (Orientation == Direction.East) { ifEast(); } else if (Orientation == Direction.West) { ifWest(); } } ``````

With this implementation, `TurnLeft` would look like

 ```1 2 3 4 5 6 7 8 9``` ``````public void TurnLeft() { Action ifNorth = () => Orientation = Direction.West; Action ifWest = () => Orientation = Direction.South; Action ifSouth = () => Orientation = Direction.East; Action ifEast = () => Orientation = Direction.North; Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

And `MoveForward` would look like

 ```1 2 3 4 5 6 7 8 9``` ``````public void MoveForward() { Action ifNorth = () => Location=Location.AdjustYBy(1); Action ifSouth = () => Location=Location.AdjustYBy(-1); Action ifEast = () => Location=Location.AdjustXBy(1); Action ifWest = () => Location=Location.AdjustXBy(-1); Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

The primary advantage of this approach is that in order to call `Execute`, you have to pass a parameter for the different directions. If you fail to do so, the code will fail to compile, which forces developers to handle the various use cases.

Furthermore, if there’s a bug in any of the `Actions`, then for troubleshooting, we’d need to know what method caused the problem and what the rover’s `Orientation` was and we can quickly figure out what the problem is.

##### Drawbacks

When using this approach, one thing to keep in mind is if we need to support additional `Direction`s in the future. The `Execute` method is already taking in four parameters and keeping them in the right order is difficult enough. What about five, six, or ten directions to support? The function signature would quickly become unwieldy.

In addition, the other downside to this approach is that if any of the `Action`s were to become much more complicated, it would start cluttering up the respective `Move` or `Turn` methods.

#### Using an Object-Oriented Approach

Now that we have a method that can operate given the Rover‘s Orientation, another approach is to introduce the Strategy pattern where we would need to create the following types

• `IMovementStrategy` – an interface that lists the different kinds of movements that can be done (currently `MoveForward`, `MoveBackward`, and `TurnLeft`)
• `NorthMovementStrategy` – a new class that implements the `IMovementStrategy` and is responsible for the various business rules when moving and facing `North`
• `GetMovementStrategy` – a method in `Rover` that for the current `Orientation`, returns the right implementation of `IMovementStrategy`
• Update the existing move methods to use `GetMovementStrategy`

First, let’s take a look at the `IMovementStrategy` definition

 ```1 2 3 4 5 6``` ``````internal IMovementStrategy() { Coordinate MoveForward(Coordinate coordinate); Coordinate MoveBackward(Coordinate coordinate); Direction TurnLeft(); } ``````

The key takeaway for this type is that if we need to add an additional movement (like `TurnRight`), we’ll need to update this interface. Taking a closer look, we’ve defined the signatures for all of the methods to return a value (either a `Location` or a `Direction`). We have to make this change because no `Strategy` will have access to the `Rover` itself, so it’ll need to return the correct value for `Rover` to hold onto.

Next, let’s take a look at an example implementation for when the `Orientation` is `North`

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````internal class NorthMovementStrategy : IMovementStrategy { public Coordinate MoveForward(Coordinate coordinate) { return coordinate.AdjustYBy(1); } public Coordinate MoveBackward(Coordinate coordinate) { return coordinate.AdjustYBy(-1); } public Direction TurnLeft() { return Direction.West; } } ``````

If you look closer, we’ve essentially moved the business rules for the three methods from the existing business rules. We would repeat this process for the other `Direction`s (yielding a `SouthMovementStrategy`, an `EastMovementStrategy`, and a `WestMovementStrategy`)

Now that we have the various strategies in place, we can create the `GetMovementStrategy` method

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````private IMovementStrategy GetStrategy() { if (Orientation == Direction.North) { return new NorthMovementStrategy(); } else if (Orientation == Direction.South) { return new SouthMovementStrategy(); } else if (Orientation == Direction.East) { return new EastMovementStrategy(); } else if (Orientation == Direction.West) { return new WestMovementStrategy(); } } ``````

Which then would allow us to refactor `TurnLeft` as the following

 ```1 2 3 4 5``` ``````public void TurnLeft() { var movementStrategy = GetMovementStrategy(); Orientation = movementStrategy.TurnLeft(); } ``````

And `MoveForward` as

 ```1 2 3 4 5``` ``````public void MoveForward() { var movementStrategy = GetMovementStrategy(); Location = movementStrategy.MoveForward(Location); } ``````

When using this approach, we can easily extend functionality when new `Direction`s are added. For example, if we added `NorthEast`, then we would create a new `MovementStrategy`, have it implement the interface and fill in business rules (also allowing us to easily add tests as we go). From there, we would update the `GetMovementStrategy` method to return the new strategy. By adding new functionality by primarily writing new code and making very little modifications to existing code, we can adhere to the Open/Closed Principle from SOLID design.

##### Drawbacks

The major drawback of this approach is that we had to create a lot of boilerplate code to make everything hang. One interface, four implementations, and a factory method for creating the appropriate strategy for a given `Orientation`.

The other, more subtle, drawback is that one must be aware of the pivot point of change. For example, we originally made this refactor based on strategies of what to do when faced in a given `Direction`. This made sense as an easy refactor. However, we’ve now made it easy to support a new `Direction` when added, but if we were to add a new `Command` instead, we would update the `IMovementStrategy` with the new method which would break all implementations. Once that happens, we have no choice but to implement the whole feature at once.

Personally, I’m a proponent of delivering value in small chunks and verify that we’re building the right thing, but in this case, this approach doesn’t make that easy.

#### Start the Refactor

Given the above options, I’m going to choose the more functional approach mostly because the business rules in my case are one-liners. If they were more complex, then I’d lean heavily more towards the `Strategy` pattern.

With that in mind, I’m going to go ahead and define the general `Execute` method as such

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````private void Execute(Action ifNorth, Action ifSouth, Action ifEast, Action ifWest) { if (Orientation == Direction.North) { ifNorth(); } else if (Orientation == Direction.South) { ifSouth(); } else if (Orientation == Direction.East) { ifEast(); } else if (Orientation == Direction.West) { ifWest(); } } ``````

Once that’s in place, I can go ahead and refactor `TurnLeft` to use the `Execute` method.

 ```1 2 3 4 5 6 7 8 9``` ``````public void TurnLeft() { Action ifNorth = () => Orienation = Direction.West; Action ifWest = () => Orientation = Direction.South; Action ifSouth = () => Orientation = Direction.East; Action ifEast = () => Orientation = Direction.North; Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

Now that I’ve updated `TurnLeft`, I can run the tests to make sure I didn’t break functionality. This is where the power of automated tests come to play. I can have higher confidence that my refactor didn’t break anything because of the test suite.

After verifying that the tests pass for `TurnLeft`, I’ll continue refactoring `MoveForward`

 ```1 2 3 4 5 6 7 8 9``` ``````public void MoveForward() { Action ifNorth = () => Location=Location.AdjustYBy(1); Action ifSouth = () => Location=Location.AdjustYBy(-1); Action ifEast = () => Location=Location.AdjustXBy(1); Action ifWest = () => Location=Location.AdjustXBy(-1); Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

and `MoveBackward` using the same technique

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19``` ``````public void MoveForward() { Action ifNorth = () => Location=Location.AdjustYBy(1); Action ifSouth = () => Location=Location.AdjustYBy(-1); Action ifEast = () => Location=Location.AdjustXBy(1); Action ifWest = () => Location=Location.AdjustXBy(-1); Execute(ifNorth, ifSouth, ifEast, ifWest); } public void MoveBackward() { Action ifNorth = () => Location=Location.AdjustYBy(-1); Action ifSouth = () => Location=Location.AdjustYBy(1); Action ifEast = () => Location=Location.AdjustXBy(-1); Action ifWest = () => Location=Location.AdjustXBy(1); Execute(ifNorth, ifSouth, ifEast, ifWest); } ``````

### One Final Touch

So at this point, we’ve successfully refactored `MoveForward`, `MoveBackward`, and `TurnLeft` to use `Execute` instead of their own logic, but the more I look at `Execute`, the more I want to convert the `if/else` into a `switch` statement because a `switch` is going to force us to implement the different `Direction`s whereas the `if/else` pattern did not. So let’s go ahead and make that change.

 ``` 1 2 3 4 5 6 7 8 9 10``` ``````public void Execute(Action ifNorth, Action ifSouth, Action ifEast, Action ifWest) { switch(Orientation) { case Direction.North: ifNorth(); break; case Direction.South: ifSouth(); break; case Direction.East: ifEast(); break; case Direction.West: ifWest(); break; } } ``````

And we can verify that our refactored worked like a top!

### Wrapping Up

At this point, we’ve made some good changes to the `Rover` with how the various methods work by examining the duplication (the `if/else`), extracting the duplication to a single area, and the compared the functional approach and the OOP approach via the Strategy pattern. In the next post, we’ll take on implementing `TurnRight` and see how our new refactor works in practice when adding new functionality!

## Mars Rover – Implementing Rover : Turning Left

Welcome to the seventh installment of Learning Through Example – Mars Rover! In this post, we’re going to start driving out the functionality for the `Rover` and the business rules for turning left! First, we’ll take a look at the requirements to make sure we have an idea of what’s needed. From there, we’ll start implementing the requirements. By the end of this post, we’ll have a `Rover` that can do 3/4 of the possible commands!

### Turning in Place By Turning Left

If we look back at the original requirements for turning left, we find this single line as the requirement

When the rover is told to turn left, it will rotate 90 degrees to the left, but not change its location

Given this requirement, we’re able to double check with our Subject Matter Expert that the `Rover` is essentially rotating in place which yields the following requirements.

• Given the `Rover` is facing `North`, when it turns left, then the `Rover` should be facing `West` at the same Coordinate
• Given the `Rover` is facing `West`, when it turns left, then the `Rover` should be facing `South` at the same Coordinate
• Given the `Rover` is facing `South`, when it turns left, then the `Rover` should be facing `East` at the same Coordinate
• Given the `Rover` is facing `East`, when it turns left, then the `Rover` should be facing `North` at the same Coordinate

Even though we’ve not written tests that have this exact setup, it looks like we should be able to use that as a start while we’re implementing. So let’s go ahead tackle the first requirement!

### Red/Green/Refactor For Rover Facing North

Leaning on lessons learned previously, we can write the following test for when the `Rover` is facing `North`.

 ``` 1 2 3 4 5 6 7 8 9 10 11``` ``````[Test] public void AndFacingNorthThenTheRoverFacesWest() { var rover = new Rover {Orientation=Direction.North}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.West, rover.Orientation); } ``````

Not too bad of a setup! First, we create the `Rover` and capture its `initialLocation`. From there, we call our new method, `TurnLeft` which doesn’t exist yet, but will soon. After `TurnLeft` has been called, we check to make sure that our `Location` is the same and that our `Orientation` has been updated accordingly.

Now let’s write just enough code to pass.

 ```1 2 3 4 5 6``` ``````public void TurnLeft() { if (Orientation == Direction.North) { Orientation = Direction.West; } } ``````

Pretty straightforward implementation and is good enough to make the test pass. Not much to refactor at this point so let’s go ahead and work on the next test case.

### Red/Green/Refactor For Rover Facing West

For the next test, let’s go ahead and write one for when the `Rover` faces `West`

 ``` 1 2 3 4 5 6 7 8 9 10 11``` ``````[Test] public void AndFacingWestThenTheRoverFacesSouth() { var rover = new Rover {Orientation=Direction.West}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.South, rover.Orientation); } ``````

And now enough code to make it pass

 ```1 2 3 4 5 6 7 8 9``` ``````public void TurnLeft() { if (Orientation == Direction.North) { Orientation = Direction.West; } else if (Orientation == Direction.West) { Orientation = Direction.South; } } ``````

Once again, now that we have passing tests, is there anything we want to refactor? The business rules look to be simple enough so I don’t feel the need to refactor those. When we look at the test code, the test seems straightforward and I’m not sure what I’d simplify.

Time to commit these changes and on to the next requirement.

### Red/Green/Refactor For Rover Facing South

Third verse same as the first, we can write a failing test for when the `Rover` faces `South`.

 ``` 1 2 3 4 5 6 7 8 9 10 11``` ``````[Test] public void AndFacingSouthThenTheRoverFacesEast() { var rover = new Rover {Orientation=Direction.South}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.East, rover.Orientation); } ``````

And now enough code to make it pass

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````public void TurnLeft() { if (Orientation == Direction.North) { Orientation = Direction.West; } else if (Orientation == Direction.West) { Orientation = Direction.South; } else if (Orientation == Direction.South) { Orientation = Direction.East; } } ``````

With everything passing again, we can pause to rethink about refactoring but so far so good from my perspective. There are maybe some superficial changes that could be made, but I can’t make a strong enough argument to implement them.

Time to commit and tackle the last requirement!

### Red/Green/Refactor for Rover Facing East

Let’s go ahead and write the final test for when the `Rover` faces `East`

 ``` 1 2 3 4 5 6 7 8 9 10 11``` ``````[Test] public void AndFacingEastThenTheRoverFacesNorth() { var rover = new Rover {Orientation=Direction.East}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } ``````

And now enough code to make it pass

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````public void TurnLeft() { if (Orientation == Direction.North) { Orientation = Direction.West; } else if (Orientation == Direction.West) { Orientation = Direction.South; } else if (Orientation == Direction.South) { Orientation = Direction.East; } else if (Orientation == Direction.East) { Orientation = Direction.North; } } ``````

### There Seems To Be a Pattern

Now that we have a few tests in place, it seems like all of the tests are following a pretty straightforward pattern:

1. Create a `Rover` with a particular `Orientation`
2. Get the starting `Location`
3. Call `TurnLeft`
4. Verify that the `Location` didn’t change
5. Verify that the `Orientation` is correct

#### Parameterized Testing

When I find myself writing tests where the tests look exactly the same and the only difference is the initial data and expected output, then I start thinking about how to parameterize the test so that the test is run multiple times, but with different parameters. By making this change, we reduce the amount of test code written, without sacrificing readability or maintainability.

#### When To Not Parameterize

It seems like it would be easy to write tests in this fashion, so why don’t we use this technique all the time?

The primary reason why we wouldn’t want to use this approach is if we would need to pass in a ton of parameters in order to make this test generic enough. A general guideline I use is that if the total parameters are three or less, then parameterization is a good fit. However, if I find out that I need to pass in more than three parameters, it makes me wonder if the tests are really the same test at all.

A secondary reason why this approach may not be a good fit is if it clouds our readability and debug-ability of the tests. Recall that our tests help us drive out our requirements and helps us talk in a ubiquitous language. If we can no longer do that easily, then we should not parameterize our tests.

### Refactoring

With all of that said, let’s take a look at our tests for `WhenTurningLeft` and see what each of the tests have in common.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51``` ``````[TestFixture] public class WhenTurningLeft { [Test] public void AndFacingNorthThenTheRoverFacesWest() { var rover = new Rover {Orientation=Direction.North}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.West, rover.Orientation); } [Test] public void AndFacingWestThenTheRoverFacesSouth() { var rover = new Rover {Orientation=Direction.West}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.South, rover.Orientation); } [Test] public void AndFacingSouthThenTheRoverFacesEast() { var rover = new Rover {Orientation=Direction.South}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.East, rover.Orientation); } [Test] public void AndFacingEastThenTheRoverFacesNorth() { var rover = new Rover {Orientation=Direction.East}; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(initialLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } } ``````

If we examine a bit closer, we’ll notice that the only differences are the starting `Orientation` and the expected `Orientation`. Since those are the only values that we would need to parameterize, this is a great candidate for parameterization!

So starting off slow, we’re going to refactor the `AndFacingEastThenTheRoverFacesNorth` test to use NUnit’s TestCase attribute to pass in the parameters. Even though we’re using NUnit for this functionality, most test frameworks support this concept, just with different syntax.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] [TestCase(Direction.East, Direction.North, TestName = "AndFacingEastThenTheRoverFacesNorth")] public void RoverTurningLeft(Direction start, Direction expected) { var rover = new Rover { Orientation = start }; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(expected, rover.Orientation); Assert.AreEqual(initialLocation, rover.Location); } ``````

With these changes in place, let’s break down what our approach was.

First, we added the `TestCase` attribute to the test as this allows us to specify parameters. In this case, we’re passing in two parameters (`Direction.East` and `Direction.North`). In addition, we’re also giving this `TestCase` a unique test name by setting the `TestName` property to `AndFacingEastThenTheRoverFacesNorth`. By setting this property, we’re controlling what this test will show up in the test runner.

Second, we changed the signature of the test method to take in two `Direction`s, one for the `start` and the other for the `expected` direction for `Rover`. These new parameters line up with the ordering of parameters in the `TestCase`. In addition, since this test is going to be a bit more generic, I renamed this method to `RoverTurningLeft` because the `TestName` is going to have my requirement and this method is the generic shell.

Finally, we updated how we initialized the `Rover` by setting it’s `Orientation` to be `start` and we changed our `Assert` to be on `expected`.

### Verifying The Changes

With this new test in place, let’s run it and verify that our changes worked

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] [TestCase(Direction.North, Direction.West, TestName = "AndFacingNorthThenTheRoverFacesWest")] [TestCase(Direction.West, Direction.South, TestName = "AndFacingWestThenTheRoverFacesSouth")] [TestCase(Direction.South, Direction.East, TestName = "AndFacingSouthThenTheRoverFacesEast")] [TestCase(Direction.East, Direction.North, TestName = "AndFacingEastThenTheRoverFacesNorth")] public void RoverTurningLeft(Direction start, Direction expected) { var rover = new Rover { Orientation = start }; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(expected, rover.Orientation); Assert.AreEqual(initialLocation, rover.Location); } ``````

And if we run our test suite, we verify that everything passes!

With this in place, we can remove the other tests in this file, which yields the following test class.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19``` ``````[TestFixture] public class WhenTurningLeft { [Test] [TestCase(Direction.North, Direction.West, TestName = "AndFacingNorthThenTheRoverFacesWest")] [TestCase(Direction.West, Direction.South, TestName = "AndFacingWestThenTheRoverFacesSouth")] [TestCase(Direction.South, Direction.East, TestName = "AndFacingSouthThenTheRoverFacesEast")] [TestCase(Direction.East, Direction.North, TestName = "AndFacingEastThenTheRoverFacesNorth")] public void RoverTurningLeft(Direction start, Direction expected) { var rover = new Rover { Orientation = start }; var initialLocation = rover.Location; rover.TurnLeft(); Assert.AreEqual(expected, rover.Orientation); Assert.AreEqual(initialLocation, rover.Location); } } ``````

Already we can see how easy it would be to extend this test suite if a new `Direction` were to be added by adding the new `TestCase` and updating the other ones as needed.

### Wrapping Up

Goodness, just like that we have a `Rover` that knows how to `MoveForward`, `MoveBackward`, and `TurnLeft`! In this post, we added some new functionality to `Rover` by first examining the requirements and implementing them one at a time. From there, we noticed during our refactor step that our test code looked similar, just differing on inputs. This, in turn, inspired us to look at parameterized testing which allowed us to drastically reduce the amount of code needed for the various use cases and allows us to add additional cases easier in the future. In the next post, we start taking a look at some interesting patterns that `Rover` is exhibiting in its three methods.

## Mars Rover – Implementing Rover : Moving Backward

Welcome to the sixth installment of Learning Through Example – Mars Rover! In this post, we’ll pick up from where we left off with `Rover` and start implementing the rules for the `Rover` to move backward!

Just like last time, we’ll first examine what it means for the `Rover` to move backward by looking over the requirements in deeper detail. Once we have a better understanding, we’ll start driving out the functionality by focusing on a simple case and building more complexity. By the end of this post, we’ll have a `Rover` that will know how to move backward when facing any `Direction`!

### So What Does It Mean To Move Backward?

If we look back at the original requirements for moving backward, we find this single line with regards to moving backward

When the rover is told to move backward, then it will move rover unit away from the direction it’s facing

Hmm, based on our previous experience with implementing `MoveForward`, I have a good idea of the requirements and after double-checking with our Subject Matter Expert, we confirm that our assumption is correct and derive the following requirements.

• Given the `Rover` is facing North, when it moves forward, then its `Y` value decreases by 1
• Given the `Rover` is facing South, when it moves forward, then its `Y` value increases by 1
• Given the `Rover` is facing East, when it moves forward, then its `X` value decreases by 1
• Given the `Rover` is facing East, when it moves forward, then its `X` value increases by 1

Great, we have enough information to get started so we can start demonstrating the software and get quicker feedback!

### Red/Green/Refactor For Rover Facing North

Given the lessons learned when writing tests for when implementing move forward, we can write the following test.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] public void AndFacingNorthThenYDecreasesByOne() { var rover = new Rover { Orientation = Direction.North }; var initialLocation = rover.Location; rover.MoveBackward(); var expectedLocation = new Coordinate(initialLocation.X, initialLocation.Y - 1); Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } ``````

Now let’s write just enough code to pass.

 ```1 2 3 4``` ``````public void MoveBackward() { Location=Location.AdjustYBy(-1); } ``````

Not too shabby, we’ve got enough code in place to make everything pass so let’s take a look at refactoring. From the business rules, `MoveBackward` is too simple to need a refactor, though I have a suspicion about what the final look of the method will look like. From the test code, the test is pretty straightforward and looks a ton like the tests we wrote for `MoveForward`.

With all of that in mind, let’s go ahead and commit these changes and go to the next requirement!

### Red/Green/Refactor For Rover Facing South

Once again, we can write a failing test for when the `Rover` faces `South`

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] public void AndFacingSouthThenYIncreasesByOne() { var rover = new Rover { Orientation = Direction.South }; var initialLocation = rover.Location; rover.MoveBackward(); var expectedLocation = new Coordinate(initialLocation.X, initialLocation.Y + 1); Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.South, rover.Orientation); } ``````

And now enough code to make it pass

 ```1 2 3 4 5 6 7``` ``````public void MoveBackward() { if (Orientation == Direction.North) { Location=Location.AdjustYBy(-1); } Location = Location.AdjustYBy(1); } ``````

Once again, now that we have passing tests, is there anything we want to refactor? The business rules look to be simple enough so I don’t feel the need to refactor those. When we look at the test code, the test seems straightforward and I’m not sure what I’d simplify.

Time to commit these changes and on to the next requirement.

### Red/Green/Refactor For Rover Facing East

Third verse same as the first, we can write a failing test for when the Rover faces East

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] public void AndFacingEastThenXDecreasesByOne() { var rover = new Rover { Orientation = Direction.East }; var initialLocation = rover.Location; rover.MoveBackward(); var expectedLocation = new Coordinate(initialLocation.X - 1, initialLocation.Y); Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.East, rover.Orientation); } ``````

And now enough code to make it pass

 ``` 1 2 3 4 5 6 7 8 9 10``` ``````public void MoveBackward() { if (Orientation == Direction.North) { Location=Location.AdjustYBy(-1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(1); } Location = Location.AdjustXBy(-1); } ``````

With everything passing again, we can pause to rethink about refactoring but so far so good from my perspective. There are maybe some superficial changes that could be made, but I can’t make a strong enough argument to implement them.

Time to commit and tackle the last requirement!

### Red/Green/Refactor for Rover Facing West

Let’s go ahead and write the final test for when the `Rover` faces West

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] public void AndFacingWestThenXIncreasesByOne() { var rover = new Rover { Orientation = Direction.West }; var initialLocation = rover.Location; rover.MoveBackward(); var expectedLocation = new Coordinate(initialLocation.X + 1, initialLocation.Y); Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.West, rover.Orientation); } ``````

And now enough code to make it pass

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````public void MoveBackward() { if (Orientation == Direction.North) { Location=Location.AdjustYBy(-1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.East) { Location = Location.AdjustXBy(-1); } if (Orientation == Direction.West) { Location = Location.AdjustXBy(1); } } ``````

### How Does Rover Look?

With the final test in place, let’s take a look at `Rover` looks like!

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} public Rover() { Orientation = Direction.North; Location = new Coordinate(){X=0, Y=0}; } public void MoveForward() { if (Orientation == Direction.North) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(-1); } if (Direciton == Direction.East) { Location = Location.AdjustXBy(1); } if (Orientation == Direction.West) { Location = Location.AdjustXBy(-1); } } public void MoveBackward() { if (Orientation == Direction.North) { Location=Location.AdjustYBy(-1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.East) { Location = Location.AdjustXBy(-1); } if (Orientation == Direction.West) { Location = Location.AdjustXBy(1); } } } ``````

Overall, `Rover` is looking to be in a good spot, however, one thing that stands out is that `MoveForward` and `MoveBackward` look similar due to their matching `if` statements. When I see duplication like this, I start thinking about how possible refactoring techniques to reduce the duplication. However, it can be tough to see a pattern before it establishes.

### When to Refactor

When it comes to refactoring to a pattern, I like to have three or more examples so I have a better idea of what use cases need to be supported. A common mistake I see developers make is that they start implementing a pattern before really understanding the problem. My approach is to refactor to a pattern when it makes sense and not before.

Circling back to this duplicated ifs, I’ve got a hunch that `TurnLeft` and `TurnRight` will follow a similar approach but I’m curious to know what they’re going to look like and I don’t want to refactor too early. So taking my own advice, I’m going to go ahead and skip refactoring `MoveForward` and `MoveBackward` until I at implement `TurnLeft` as that may change my approach.

### Wrapping Up

Just like that, we now have a `Rover` that knows how to both `MoveForward` and `MoveBackward`! Like before, we first started by examining the requirements and coming up with our various test cases. From there, we were able to drive out the functionality by using red-green-refactor and building our software with tests. In the next post, we’ll take a look at implementing the logic for turning left!

## Mars Rover – Implementing Rover : Moving Forward

Welcome to the fifth installment of Learning Through Example – Mars Rover! In this post, we’ll pick up from where we left on with `Rover` and start digging into how to make it move forward! We’ll first examine what it means for the `Rover` to move forward by looking over the requirements in deeper detail. Once we have a better understanding, we’ll start driving out the functionality by focusing on a simple case and building more complexity. By the end of this post, we’ll have a `Rover` that will know how to move forward when facing any `Direction`!

### So What Does It Mean To Move Forward?

If we look back at the original requirements for moving forward, we find this single line with regards to moving forward

When the rover is told to move forward, then it will move one rover unit in the direction it’s facing

Super helpful, right? I don’t know about you, but this not nearly enough information for us to start our work because I’m not sure what that actually means!

In this case, we will have a more in-depth conversation with our Subject Matter Expert and we’ll find out that depending on the `Orientation` of the `Rover` the `Rover`‘s `Location` will change. Through additional conversations, we end up figuring out some more concrete business rules for when the `Rover` moves forward.

• Given the `Rover` is facing North, when it moves forward, then its `Y` value increases by 1
• Given the `Rover` is facing South, when it moves forward, then its `Y` value decreases by 1
• Given the `Rover` is facing East, when it moves forward, then its `X` value increases by 1
• Given the `Rover` is facing East, when it moves forward, then its `X` value decreases by 1

Great, we have enough information to get started so we can start demonstrating the software and get quicker feedback!

### Writing The First Test

Let’s begin writing our first test for the `Rover` moving forward! We’ll be leveraging the same naming guidelines mentioned in part three to help make the use cases standout in our tests

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover() { Orientation = Direction.North}; // Act rover.MoveForward(); // Assert Assert.AreEqual(1, rover.Coordinate.Y); } ``````

So far, so good! The test matches the intent behind the name and a new developer can see that we’ve created a `Rover` facing `North`, called its `MoveForward` method and making sure that the `Y` property is 1.

If we try running the test, it will fail because `Rover` doesn’t have a `MoveForward` method, so let’s go ahead and write a simple implementation.

 ```1 2 3``` ``````public void MoveForward() { } ``````

Even though there’s no business logic implemented, it’s enough code for our test to compile and if we run the test, the test fails because `Y` is not 1.

With that in mind, let’s go ahead and write the simplest thing that could work just to check our approach.

 ```1 2 3 4``` ``````public void MoveForward() { Location.Y+=1; } ``````

Hmm, when we try to compile this code though, we get the following error

What’s going on here?

### When Things Go Off Track

The error is caused due to the interaction of `struct` and the `Location` property implementation. If you recall, `struct`s are value types which means when you assign them to a variable, the variable has its own copy of the `struct`, not the reference.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17``` ``````// Let's create a location var location = new Coordinate {X = 0, Y = 0}; // And now let's have newLocation have the same value, NOTE: This isn't a reference to location! var newLocation = location; // And if we check if both are equal, they are! Console.WriteLine(location.Equals(newLocation)); // True // Now let's change location's X value location.X = 200; // That works just fine, but if we check what newLocation is, we see that it's stil (0, 0) Console.WriteLine(\$"newLocation = ({newLocation.X}, {newLocation.Y})"); // Which means when we compare, they're not the same! Console.WriteLine(location.Equals(newLocation)); // False ``````

So what does that have to do with the `Location` property? Well, we’ve defined it as an auto-property which is syntactic sugar for telling the compiler to generate a backing field for the property and to implement default `get` and `set` logic.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16``` ``````// Given this definition of Rover public class Rover { public Coordinate Location {get; set} } // This is syntactic sugar for the following public class Rover { private Coordinate _location; public Coordinate Location { get => _location; set => _location = value; } } ``````

So the problem arises from how `get` is working. It’s returning the backing field which is going to be stored as a variable for use. Recall from above that when we do that type of assignment, we’re working on a copy of the value. So if we try to make changes to the copy, the changes won’t make it back to the backing field which in turn won’t ever update the `Location` property!

### Getting Back On Track

So good job on the compiler letting us know that there’s a problem even if the message is a bit obscure! But how do we fix the problem? Well, to get the code to compile, instead of updating the `Y` property of `Location`, let’s go ahead and update the entire `Location` property instead.

 ```1 2 3 4``` ``````public void MoveForward() { Location = new Coordinate { X = Location.X, Y = Location.Y + 1 }; } ``````

And if we try to run our test, we find that it now passes, hooray!

### Refactoring The Code

For those keeping track at home, we’re doing a pretty good job of following Test Drive Development (TDD) principles in that we first wrote a failing test, then wrote enough code to make it pass. The third step is to refactor our code (both production and test) to make it easier to work with or to make it more robust.

If we take a look at the `MoveForward` method, it’s pretty simple and there’s not much we can refactor there for now.

 ```1 2 3 4``` ``````public void MoveForward() { Location = new Coordinate { X = Location.X, Y = Location.Y + 1 }; } ``````

### Is Our State Correct?

So if our business code is pretty good, let’s take a look at our test and see what can be done.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````[Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover() { Orientation = Direction.North}; // Act rover.MoveForward(); // Assert Assert.AreEqual(1, rover.Coordinate.Y); } ``````

Looking at this code, one thing that stands out is that we’re checking that `Y` got updated, but we’re not verifying that `X` nor the `Orientation` didn’t change. In fact, if we change the implementation of `MoveForward` to set the X value to be 200 and change the `Orientation` to be `South`, the test would still pass and it clearly shouldn’t!

Thankfully, we can mediate this oversight by creating an `expectedLocation` which will have the expected `X` and `Y` values for the Rover. In addition, we’ll update one `Assert` to use this new value and add another `Assert` to verify the `Orientation`

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14``` ``````[Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.North}; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = 0, Y = 1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } ``````

Nice! We’re now much more explicit about our expectations of `Rover` should be at this exact `Location` and should have this exact `Orientation`, otherwise, fail the test.

### Are There Hidden Assumptions?

While looking at this test, there’s one more subtle issue with code, can you spot it?

We’re making an assumption about what the initial `Location` for the `Rover`! What if the `Rover` started off at (5, 5) instead of (0, 0)? This test would fail, but not for the right reason (an error in the production code), but due to fragility in the way the test was written.

If we wanted to harden this test, we have two approaches

#### Setting the Location

We could change our `Arrange` step to explicitly set the initial location of `Rover` to be (0, 0). This would guarantee the initial setup and if the default `Location` were to ever change, our test would still pass.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18``` ``````[Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover { Orientation = Direction.North, Location = new Coordinate {X = 0, Y = 0}, }; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = 0, Y = 1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } ``````

#### Capturing the Initial Location

When we look at this test and the code we’re testing, the key thing that we’re wanting to test is that the right value was modified correctly (in this case either by +1 or -1). Given that, we could update our `Arrange` step to capture what the initial `Location` was and then update our `Assert` step to know about the location.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.North}; var initialLocation = rover.Location; // capturing the initial location // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X, Y = initialLocation.Y+1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } ``````

Given the two approaches, I like the idea of capturing the initial location, so that’s what I’m going to go with.

Now that we have a passing test for `Rover` and moving forward, let’s go ahead and implement another piece of functionality by writing a test for when the `Rover` is facing `South`

#### Red/Green/Refactor for Rover Facing South

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] public void AndFacingSouthThenYDecreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.South}; var initialLocation = rover.Location; // capturing the inital location // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X, Y = initialLocation.Y-1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.South, rover.Orientation); } ``````

And write enough code to make it pass!

 ```1 2 3 4 5 6 7 8 9``` ``````public void MoveForward() { if (Orientation == Direction.North) { Location = new Coordinate { X = Location.X, Y = Location.Y + 1 }; } else { Location = new Coordinate { X = Location.X, Y = Location.Y - 1}; } } ``````

Now that we have a passing test suite again, is there anything we want to refactor? Are there any patterns starting to emerge?

From the business code, `MoveForward` seems pretty straightforward and I’m not sure what refactor I could do there that would make a lot of sense right now.

If we take a look at the test code, I’m noticing that our two tests so far look almost like carbon copies of each other. In fact, if we take a closer look, it seems like the only differences between the two tests are the `Rover`‘s `Orientation` and the `expectedLocation`. I’m really tempted to refactor this code to be a bit more DRY and remove some duplication. However, I’ve only seen two examples so far and before I refactor to a pattern, I actually want the pattern to manifest first so I know what the pattern is.

Let’s keep writing some more tests and see what pattern emerges!

#### Red/Green/Refactor for Rover Facing East

Now that the `Rover` can move forward when facing `North` or `South`, let’s go ahead and write a test for when the `Rover` faces East.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` `````` [Test] public void AndFacingEastThenXIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.East}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X+1, Y = initialLocation.Y}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.East, rover.Orientation); } ``````

With the test in place, let’s write enough code to make it pass.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````public void MoveForward() { if (Orientation == Direction.North) { Location = new Coordinate { X = Location.X, Y = Location.Y + 1 }; } if (Orientation == Direction.South) { Location = new Coordinate { X = Location.X, Y = Location.Y - 1}; } if (Direction == Direction.East) { Location = new Coordinate {X = Location.X + 1, Y = Location.Y}; } } ``````

With this passing test, let’s take a look at possible refactoring opportunities.

##### Refactoring Coordinate

If we look at the production code, I’m getting really tired of having to write `Location = new Coordinate {X=Location.X..., Y=Location.Y...}` because I know I’m going to have to write this similar logic for the last remaining test for moving forward and probably something similar for moving backward.

Looking at the way we’ve been modifying `Coordinate`, it seems like we’re every modifying `X` or `Y` by a set amount, so what if we wrote some methods that could adjust either `X` or `Y`?

If we take a look at `Coordinate`, it seems like we have a struct with the two properties in mention, so let’s add a method called `AdjustXBy` that will return a new `Coordinate` with `X` adjusted by that value and keep `Y` the same

 ```1 2 3 4 5 6 7 8 9``` ``````public struct Coordinate { public int X {get; set;} public int Y {get; set;} public Coordinate AdjustXBy(int adjustment) { return new Coordinate {X = X+adjustment, Y=Y}; } ``````

With this change in place, let’s go ahead and update our `MoveForward` method to use this new code!

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````public void MoveForward() { if (Orientation == Direction.North) { Location = new Coordinate { X = Location.X, Y = Location.Y + 1 }; } if (Orientation == Direction.South) { Location = new Coordinate { X = Location.X, Y = Location.Y - 1}; } if (Direction == Direction.East) { Location = Location.AdjustXBy(1); } } ``````

Even in this small example, this addition is already more concise of our intent than the other two cases. After doing a quick verification that the test still passes (otherwise the refactor isn’t a refactor), let’s go ahead and add a new method to `Coordinate` called `AdjustYBy` that is similar to `AdjustXBy`

 ```1 2 3 4``` `````` public Coordinate AdjustYBy(int adjustment) { return new Coordinate {X=X, Y=Y+adjustment}; } ``````

And let’s go ahead and update `MoveForward` to take advantage of this new functionality

 ``` 1 2 3 4 5 6 7 8 9 10 11 12``` ``````public void MoveForward() { if (Orientation == Direction.North) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(-1); } if (Direciton == Direction.East) { Location = Location.AdjustXBy(1); } } ``````

After making that much change to the production code, we’ll go ahead and run our test suite again and it seems like the change is working as expected, nice!

##### Refactoring Test Code

Now that we’ve refactored the business rules and our test suite is passing correctly, we can take a look at refactoring our test code. With the addition of the `East` test, the tests are definitely following a pattern and I should be able to extract out that logic to a single test and then pass in different parameters (even though the link is to NUnit, most test frameworks support this concept).

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` `````` [Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.North}; var initialLocation = rover.Location; // capturing the inital location // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X, Y = initialLocation.Y+1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } ``````
 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] public void AndFacingSouthThenYDecreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.South}; var initialLocation = rover.Location; // capturing the inital location // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X, Y = initialLocation.Y-1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.South, rover.Orientation); } ``````
 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] public void AndFacingEastThenXIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.East}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X+1, Y = initialLocation.Y}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.East, rover.Orientation); } ``````

Given the differences between the tests, we would need to extract the starting `Direction` and the `expectedLocation` to be parameters. However, the `expectedLocation` is based on the initialLocation which is currently based on whatever the `Rover` defaults to.

Based on that chain, if we wanted to do this refactor, we would have to pass in a `Rover` as the parameter and I really don’t like that idea because if `Rover` grows to be bigger, then creating a `Rover` becomes more involved and I don’t want to inflict that onto my test. In addition, one thing that is nice about our tests is that they’re easy to read and to follow their logic which has a ton of value given that developers spend more time reading code than writing code.

All of that to say, that even though the tests look similar, I’m going to pass on refactoring to a single unified test because I’d be trading readability for removing duplication and these tests are small enough that I don’t think it’s that much technical debt to take on.

#### Red/Green/Refactor for Rover Facing West

With the latest test, we’re 3/4 of the way through implementing `MoveForward`, so let’s go ahead and write another failing test for when the `Rover` faces `West`.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````[Test] public void AndFacingWestThenXDecreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.West}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X-1, Y = initialLocation.Y}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.West, rover.Orientation); } ``````

With the test in places, let’s write enough code to make the test pass by taking advantage of `Coordinate.AdjustXBy`

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````public void MoveForward() { if (Orientation == Direction.North) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(-1); } if (Direciton == Direction.East) { Location = Location.AdjustXBy(1); } if (Orientation == Direction.West) { Location = Location.AdjustXBy(-1); } } ``````

And with this latest addition, not only do we have a passing test suite, but we’ve also covered the business rules for when the `Rover` moves forward, completing this part of the kata, nice!

As a recap, here’s what `Rover` and `WhenMovingForward` looks like

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} public Rover() { Orientation = Direction.North; Location = new Coordinate(){X=0, Y=0}; } public void MoveForward() { if (Orientation == Direction.North) { Location = Location.AdjustYBy(1); } if (Orientation == Direction.South) { Location = Location.AdjustYBy(-1); } if (Direciton == Direction.East) { Location = Location.AdjustXBy(1); } if (Orientation == Direction.West) { Location = Location.AdjustXBy(-1); } } } ``````
 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68``` ``````[TestFixture] public class WhenMovingForward() { [Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.North}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X, Y = initialLocation.Y+1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.North, rover.Orientation); } [Test] public void AndFacingSouthThenYDecreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.South}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X, Y = initialLocation.Y-1}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.South, rover.Orientation); } [Test] public void AndFacingEastThenXIncreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.East}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X+1, Y = initialLocation.Y}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.East, rover.Orientation); } [Test] public void AndFacingWestThenXDecreasesByOne() { // Arrange var rover = new Rover {Orientation = Direction.West}; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate { X = initialLocation.X-1, Y = initialLocation.Y}; Assert.AreEqual(expectedLocation, rover.Location); Assert.AreEqual(Direction.West, rover.Orientation); } } ``````

### Wrapping Up

With this final test in place, we have the core functionality for when the `Rover` moves forward. In addition, we’ve written enough tests and functionality now that if requirements were to change, we have a pretty good guess on what the work involved would be. In the next part of the kata, we’ll start implementing a new piece of functionality!

## Mars Rover – Implementing Rover : Creation

In this installment of the Mars Rover kata, we’re going to start implementing the `Rover` type! First, we’re going to review the models that we derived in Part 2 of the series. From there, we’ll take a look at the various requirements and see which piece to start implementing. From there, we’ll write our first tests, driving the new functionality and running into a snag or two on the way. By the end of this post, we’ll be one requirement down for the kata and have a better understanding of the `Rover` type!

### Model Review

As a recap, we’ve derived the following models and implementations for the kata so far. For this post, we’re going to be spending the majority of our time working with `Rover`, but it’s good to know what our base looks like.

 ```1 2 3 4 5 6``` ``````public enum Command { MoveForward, MoveBackward, TurnLeft, TurnRight, Quit } ``````
 ```1 2 3 4``` ``````public enum Direction { North, South, East, West } ``````
 ```1 2 3 4 5``` ``````public class Coordinate { public int X {get; set;} public int Y {get; set;} } ``````
 ```1 2 3 4 5``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} } ``````

With this in mind, let’s start working on adding some new functionality to `Rover`!

### In the beginning

#### Picking an Approach

When I begin a new feature, one thing that I’m always thinking about is how do I break down the work ahead of me in such a way that I can start delivering value much faster. This doesn’t mean that I’m skipping on quality, but it does mean that I value quicker feedback than 100% test coverage. With that being said, when I look at the requirements, something that I can implement pretty quickly is that when the `Rover` starts, it should be at (0, 0) facing North.

Like everything in development, there are multiple ways we could implement this functionality

1. Provide a default constructor for `Rover` that sets those values explicitly
2. Update the Program.cs file to set those values for `Rover`

With the first approach, we’re encoding this business rule into the `Rover` type and forcing that when anyone creates an instance of `Rover`, it will always be at (0, 0) facing North which is a nice way of putting the business rule into the right component.

With the second approach, we’re going to let `Rover` be a dumb component and have some other component decide these values. The downside to this approach is that if there’s an error with `Rover`, we won’t know if it’s because of how `Rover` is behaving or how it was created.

Both approaches are valid, so I’m just going to pick one and use that for now. If later down the road we need to make a change, we’ll update as needed. With that being said, I’m leaning towards the first approach, so let’s go ahead and write our first unit test on making sure that `Rover` is facing `North`.

#### Gaining Our Bearings

Creating a unit test for `Rover` where the `Orientation` should be `North` would look like the following:

 ```1 2 3 4 5 6 7 8 9``` ``````[Test] public void ThenTheRoverIsFacingNorth() { // Arrange and Act var rover = new Rover(); // Assert Assert.AreEqual(Direction.North, rover.Orientation); } ``````

What’s interesting here is that when we run this test, it passes! But why does it pass? If we look back at `Rover`, here’s how we’ve defined it.

 ```1 2 3 4 5``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} } ``````

We don’t have any constructors defined nor are we setting values for the two properties, so how does it know that `Orientation` is `North`?

Magic?

Not quite! Since we’re not setting any value for `Orientation`, it will be whatever the default value for `Direction` is. We can determine that by using the default operator in C#.

 `1` ``````default(Direction); // North ``````

But why is `North` the default value for `Direction`?

If you remember how `Direction` was defined, we decided to define it as an enum which is really a number in disguise.

 ```1 2 3 4``` ``````public enum Direction { North, South, East, West } ``````

So what’s the default value for a number?

 `1` ``````default(int); // 0 ``````

So what’s happening here is that when the `Rover` is created, it looks for any logic in the default constructor. Since there isn’t one, it will set default values to both properties. For `Orientation`, that value will be 0 and by default, it will be the first value listed in the `Direction` enum.

So for fun, if we change `North` to be the second choice in `Direction`

 ```1 2 3 4``` ``````public Direction { South, North, East, West } ``````

then our test fails with our expected error.

I don’t know about you, but someone changing the ordering of an enum shouldn’t be causing a failing test. Luckily, resolving this issue is as simple as explicitly stating the `Orientation` in `Rover`‘s default constructor.

 ``` 1 2 3 4 5 6 7 8 9 10``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} public Rover() { Orientation = Direction.North; } } ``````

Now, our test passes even if we change the ordering of values in `Direction`!

#### Getting to Ground Zero

Now that we have our `Orientation` figured out, let’s go ahead and write our next test to make sure that the `Location` is correct.

 ```1 2 3 4 5 6 7 8 9``` ``````[Test] public void ThenTheRoverIsAt00() { // Arrange and Act var rover = new Rover(); var expectedLocation = new Coordinate{X=0, Y=0}; Assert.AreEqual(expectedLocation, rover.Location); } ``````

When we run the test, we get the following error:

Ah, yeah, that makes sense, `Location` is a `Coordinate` which is an object. Because we’ve not explicitly set `Location`, the default value is `null`.

 `1` ``````default(Coordinate); // null ``````

So let’s go ahead and update the `Rover` constructor

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} public Rover() { Orientation = Direction.North; Location = new Coordinate(){X=0, Y=0}; } } ```` So let’s re-run our test now. ```csharp [Test] public void ThenTheRoverIsAt00() { // Arrange and Act var rover = new Rover(); var expectedLocation = new Coordinate{X=0, Y=0}; Assert.AreEqual(expectedLocation, rover.Location); } ``````

What’s going on here?

#### Not All Locations Are Created Equally

When we leverage `Assert.AreEqual`, under the hood, it’s leveraging the built-in `Equals` method for the values being passed in. For primitive types, this will do a comparison by values, but if we’re comparing objects, then it will do comparison by reference.

Given this, the problem we’re running into now is that even though I have two `Coordinate`s that have the same value, since they are two different objects, then `Assert.AreEqual` will fail. We’ve got a couple of different ways to solve this problem.

##### Overriding the `Equals` Method

One way to solve the problem is by overriding the `Equals` method on the `Coordinate` class and override the logic so that two `Coordinate`s are the same if all of their properties are the same. This is a pretty solid approach to take if that’s how equality should work everywhere. With that being said, here are some things to keep in mind when using this technique.

First, if the class gains a new property, you will need to remember to update the `Equals` method, otherwise, you’ll get interesting behavior when two objects that have a single difference are being treated as the same.

Next, if you override `Equals`, then you must override GetHashCode as well. If you fail to do this, this will generate a warning during compilation time, but the bigger problem is that for two objects that are the same based on the definition of `Equals` but hash differently, then you will fail to find the item correctly in `Dictionary` and `HashSet` structures. When implementing `GetHashCode`, you should use the same properties for hashing as you would for equality checking.

Overall, I will use this approach if equality for this type needs to be by value for everywhere in the application but this isn’t my favorite approach because developers need to remember to update both `Equals` and `GetHashCode` when new properties are added.

##### Going from `class` to `struct`

The second approach we can take to have equality by value is by changing our type for `Coordinate` from a `class` to a `struct`. The cool thing about `structs` is that they by default handle equality by value so if you do need to add another property, things will work as expected. However, like all things in software, there are a couple of things to be aware of.

First, `structs` have to have an empty, default constructor. So if there are some validation rules that need to be checked in the constructor, there’s no way to force that to happen. Another effect of this drawback is that if a `struct` needs two things to exist or it shouldn’t be created, you can’t force callers to pass them in which can play havoc with making illegal states unrepresentable.

Second, when working with `struct`s, and you change one of the properties, you’re modifying a copy of the struct and not the original version.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17``` ``````public struct Date { public int Month {get; set;} public int Day {get; set;} public int Year {get; set;} } public class Order { public Date TransactionDate {get; set;} public decimal Total {get; set;} } var order = new Order{Total=9.99m}; // at this point, Order will have a Date of 0/00/0000 order.TransactionDate = new Date{Month=6, Day=22, Year=2020}; // Order has a new date! order.TransactionDate.Day = 23 // Fail to compile => Cannot modify the return value of `TransactionDate` // because it is not a variable ``````

It’s not a problem if you replace the whole struct value, but if you only want to change a part of it, you’ll need to replace the whole value. If you’ve ever worked with the `DateTime` type, you’ll notice that you can’t change values, but you can create a new `DateTime` value with updated properties.

Overall, I prefer this approach when modeling values where dependencies aren’t required and there’s not a need for validation logic.

##### Creating an `Equals` Method for Testing

The third approach you can take when checking if things are equal is by defining a custom `Equals` method that lives in my test suite and is only used for testing. The benefit of this approach is that I can now verify my objects by value, without the need of overriding two different methods. In addition, since this type of equality is only needed for testing, I can now have this logic live in the test project. In addition, I can still have validation logic and non-default constructors for my classes.

The main downside to this approach is that if there’s a new property added to the class that you’ve written custom equality logic for, you’ll need to update this method as well.

Overall, I prefer this approach when I need equality by value for testing purposes only and I don’t want to make wide-sweeping changes by changing my type from `class` to `struct`.

#### Making Locations Equal

Now that we have some more information about why the test failed and a few different approaches, let’s take a look at what approach makes sense here. First off, `Coordinate`s really don’t have any validation logic. Second, in our system, if we have two `Coordinate`s with the same values, then they should be considered the same. Given these assumptions, I’m going to go ahead and change the type definition from `class` to `struct`.

 ```1 2 3 4 5``` ``````public struct Coordinate { public int X {get; set;} public int Y {get; set;} } ``````

Now that we’ve made that change, if we re-run our test, it passes!

#### Wrapping Up

In this post, we started writing tests on `Rover`. We started off by adding a default constructor which sets the `Orientation` to `Direction.North` and explored about how setting defaults explicitly can protect us from changes in the future. From there, we wrote a test on `Location` and learned about how `Assert.AreEquals` leverages default equality and a few different approaches to solving this problem. Now that we have a way to assert against `Orientation` and `Location`, we can start writing tests for when the rover moves forward!

## Mars Rover - Intro To Testing

### What This Is and What This Isn’t

The goal of this post isn’t to try to convince you that you should be unit testing your code, but to give you enough information that if you need to unit test your code or if you’re in a codebase that expects tests, you will have the knowledge to hold your own. If you are looking for reasons why you should be testing, there are some great resources in the Additional Resources section at the end of the post!

### Unit Testing 101

At its core, unit testing is the practice of writing code that tests that your code is working correctly. Confused? It’ll make sense in a minute, I promise! If you’ve ever made changes to a project, how confident were you that your changes worked? If I had to guess, there’s a high level of confidence that your changes solved the problem. However, how confident were you that your changes didn’t break some other piece of functionality? I imagine that your confidence is a bit lower. For me, I’m reasonably confident that my changes are solid, but I’m not always sure that I didn’t break some other features elsewhere. The most straightforward approach to verify everything is working correctly is to run the application and try it out, right?

For small applications, that’s a pretty reasonable approach to take and wouldn’t take too much time. However, what if you’re working on a more complicated application? How much time is it taking for you to compile the application, launch it, and start navigating through the UI? The premise of unit testing is that we can exercise the same logic that’s running in the application but without having to go through the interface. This type of testing is generally faster and less error-prone since your test code will do the same tests over and over again. The downside is that you’ll spend more time writing code, but for me, I feel much more confident in my work when I can run the full test suite and know pretty quickly if I’ve broken something.

#### Naming Again?!

If you’ve been following along with the Mars Rover kata series then you know I’m a huge fan of using the same language as my Subject Matter Experts (SMEs) when it comes to the problem at hand as it prevents confusion when different terminology is used for the same concept.

When it comes to naming my tests, I take this approach one step further and name my tests in such a manner that if you read the class name followed by the method, then you’ll have a clear idea of what the test’s intent is. The main reason I name my tests this way is that if my test fails, I want to know what requirement or workflow is not working so I can see if it makes sense for that workflow to be impacted.

Sometimes, a test will start to fail because requirements have changed, so the test needs to be updated or removed. In other cases, the test failure reveals a contradiction in rules so it helps me if I can clearly see the use case and ask the right questions to my SMEs.

#### Framing Context with Given/When/Then

When it comes to naming my test classes and method, I borrow inspiration from the Given/When/Then naming methodology. I came across this convention when learning about Behavior Driven Development (BDD) early on in my career but I was familiar with the naming convent from working with user stories. The intent of Given/When/Then is that it provides the context, an action, and a result. Going to Mars Rover, an example user story would be

Given that the rover is at (0, 0) facing North, when it receives the move forward command, then it should be at (0, 1) facing North

Let’s break this user story down and examine the various parts:

##### Given

The Given portion of the user story sets up the context of the application. It can be as simple as Given that the user is logged into the system or as complex as Given that today is a holiday and that a user wants to make a reservation. The goal here is that someone can read this portion of the story and understand what is being accomplished. For this user story, the context is that we have a Rover that’s located at (0, 0) facing North.

##### When

The When portion of the user story gives what action is being taken in the application. At this level, we’d typically stay away from technical jargon (i.e. the user clicks the reservation button) and focus more on the workflow being accomplished. For this user story, the action is that the Rover received the Move Forward command.

##### Then

The Then portion of the user story tells us what the expected result or behavior is. It can be as simple as then the total is \$42.55 or as complex as then the sale is declined and the user is informed that there was an issue processing the payment. For this user story, we’re expecting that after the Rover receives the Move Forward command, then the rover is at (0, 1) facing North.

#### Test Structure and Naming Conventions

Now that we’ve learned a bit more about Given/When/Then, let’s talk about how this can influence your test structure. When I’m writing tests, I’ll typically place them in a unit test project that’s separate from production code so that we don’t deploy the unit tests with the production code.

In the case of Mars Rover, if I have a project called MarsRover, then I’d have a project called MarsRover.UnitTests. Once I have this new project created, I’ll create a folder called xyzTests where xyz is the name of the class I’m writing tests against. So if I’m writing tests against the Rover class in the MarsRover project, then I would have a folder called RoverTests in the MarsRover.UnitTests project.

From here, I’ll generally create a file per method or workflow that I want to test for the class. So based on our user story above, I would have a file called WhenMovingForward and this file will contain all the different tests for this functionality. Once a file is in place, we can start writing the various test methods for different behaviors. When naming methods, I will include the context for the setup and what the expectations were. By combining the test name and the method name, it will sound like a user story.

#### Organizing Your Test With Arrange/Act/Assert

At this point, we have the infrastructure in place for our tests, so how do we write a good test? Every good test will have three parts, Arrange, Act, and Assert. In the Arrange step, we’re going to focus on creating dependencies and getting the initial state setup for the test. For simple tests, this step may only consist of creating the class that we’re testing. For more complicated tests, there may be more dependencies to create, some methods to call, and possibly modifying the local environment. The Act step is where the method or property that we’re testing is called. This step should be the simplest portion of the test since it should only be a line or two of code. The third and final step is the Assert step where we check that the result we observed was correct. For simple tests, this could be a single line where check a value whereas more complicated tests may need to check various properties.

Using WhenMovingForward as an example, here’s what an example test might look like.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24``` ``````using NUnit; using System; namespace MarsRover.UnitTests.RoverTests { [TestFixture] public class WhenMovingForward() { [Test] public void AndFacingNorthThenYIncreasesByOne() { // Arrange var rover = new Rover { Orientation = Direction.North }; var initialLocation = rover.Location; // Act rover.MoveForward(); // Assert var expectedLocation = new Coordinate {X=initialLocation.X, Y=initialLocation.Y+1}; Assert.AreEqual(expectedLocation, initialLocation); } } } ``````

I like to think of Arrange/Act/Assert (AAA) as a science experiment because we have to first find a hypothesis, design some test to prove or disprove the hypothesis, get all the necessary ingredients together for the test, run the test, and see if we have evidence to support our hypothesis.

### Wrapping Up

In this post, we took a brief break from the Mars Rover kata to get a quick understanding of unit testing and the naming conventions we’ll be leveraging for the rest of the series! We first talked about the importance of naming and how if we follow Given, When, Then syntax, we can turn our user stories into readable test names for future engineers. From there, I showed you Arrange, Act, Assert notation for tests, and an example test using the convention. Next time, we’ll start implementing Rover!

## Mars Rover - Defining the Problem

In this installment, we’ll be looking at the problem description for Mars Rover. After becoming more familiar with the problem, we’ll start by identifying the terminology that we should be using when talking about the problem by defining a ubiquitous language. From there, I’ll show you how to break down the problem into various concepts and how to find the relationships between the various pieces. By the end of this post, you should feel comfortable exploring a new domain, understanding the terminology used, and defining relationships.

### Problem Description

Congratulations and welcome to the S.P.A.C.E¹ Institute, good to have you aboard! Our big focus for the year is to develop a rover that can navigate the surface of Mars! While the engineers are working on the design and building of the rover, we can focus on building the navigation module and start iterating on its design. With that in mind, here are a couple of assumptions we’re going to make for this version.

1. The rover will be traveling on a two-dimensional plane that should be modeled as a coordinate (X, Y)
2. The rover is guaranteed to be able to travel in a chosen direction (no worries about obstacles or other landmarks)

Given the above assumptions, here are the business rules that the emulation will need to follow

• When the emulation starts, the rover will always be at (0, 0) and facing North
• There are a series of commands that the rover can receive that can change its location or direction
• When the rover is told to move forward, then it will move one rover unit in the direction it’s facing
• When the rover is told to move backward, then it will move rover unit away from the direction it’s facing
• When the rover is told to turn left, it will rotate 90 degrees to the left, but not change its location
• When the rover is told to turn right, it will rotate 90 degrees to the right, but not change its location
• When the emulation is told to quit, the rover will stop receiving commands
• For the emulation, valid directions include North, East, South, and West
• In order to help troubleshoot failures with the emulation, every time a command is received, both the command received, the rover’s location, and the rover’s orientation should be logged.

¹ Simple Programming Application Checks Expertise

### Identifying the Domain

When building software, I want to understand the various business terms that are being used to describe the problem so that when I’m talking to subject matter experts (SMEs), I’m using the same terminology as they are. For those who are familiar with Domain-Driven Design, this practice of using the same terminology is known as defining a ubiquitous language and the goal is to make sure that when someone says Command, then we are all referring to the same concept. If you’ve ever worked in a codebase where something was called one thing, but the business referred to it as something different, then you are familiar with the pain of having to map between the two concepts.

#### Find The Nouns

When working to define the ubiquitous language, a common approach is to find the nouns that are being used in the description as this can create the foundation of your classes (if following Object-Oriented principles) or your types (if following Functional Programming principles).

Looking over the description again, these nouns stood out to me:

#### Find The Relationships

Once the nouns have been found, I’ll pivot to finding out how these different concepts are related to each other. One approach to finding these relationships is using “has-a” and “is-a” relationships. At a high level, if two things are related through “has-a”, then those concepts should be composed together. If two concepts have an “is-a” relationship, then I know that the concepts should be interchangeable for one another.

To help identify these relationships, I would work with the SME to understand what each of these concepts means and how they relate to each other. Since it’ll be a bit hard to simulate a conversation, here’s the information that we would learn from our SME.

• A Rover has a Location and an Orientation
• Orientation is the Direction that a Rover is facing
• Location is the coordinates that the Rover is located at
• A Command is something that a Rover receives from the User
• A Direction can be North, East, South, or West
• A Command can be Move Forward, Move Backward, Turn Left, Turn Right, or Quit

With this new understanding, our concepts and relationships would look something like this:

### Wrapping Up

In this post, we explored the problem description for the Mars Rover kata and built up our understanding of the various concepts by exploring the nouns. After finding the nouns, we leveraged “has-a” and “is-a” thinking to come up with a rough idea of how the various concepts related to one another. In the next post, we’ll be focusing on how to model these concepts in code!

## Learning Through Example – Mars Rover Kata

Over my career, I’ve spent a lot of time bringing new engineers up to speed on how to break down problems, how to write better code, and how to write automated tests. What I’ve come to find out is that there are a ton of resources on how to do each of these things individually, but not very many that brings all of these concepts together in one place. The purpose of this series is to bring all of these ideas together as we solve the Mars Rover kata.

### Purpose

For new engineers, this kata has about the right amount of complexity to explore these various concepts and help identify things to improve on. As a team lead at SentryOne, I’ve onboard interns and our associate engineers using this kata as a launch point to teach them the tooling and processes we use. In addition, this kata serves as a method to evaluate their current skills so we can help round out a solid foundation for their career.

By the end of this series, you will have a better understanding of how to break down a problem into small, deliverable pieces while being able to write tests around new functionality. Even though there will be a lot of code to look at, none of these concepts are technology-specific so I challenge you to follow along with your tech stack of choice and see how you would implement some of these concepts in that stack.

### Technologies Used

On the topic of technologies, I’ll be using the following for my implementation of this kata. As long as you find the relevant tool for your technology stack, you should be able to follow along!

## Mars Rover - Modeling Concepts

In the last post, we took a look at the problem description for Mars Rover and developed a set of concepts for the problem. From these concepts, we were able to develop common terminology and determine the relationships between the concepts. In this post, I’m going to show how I think about software design in general and how to apply them when modeling in code.

As a note, I’ll be showing code in both C# (for Object-Oriented approaches) and F# (for Functional Programming approaches). Once again, these concepts are fundamentals, but depending on your technology stack, the implementations will vary.

### Design Guidelines

When I’m designing my models, my end goal is to produce software that captures the problem at hand using the same terms that the business uses. By striving for this goal, I can have richer conversations with my stakeholders when I run into interesting interactions of various business rules and can speak to them using the right terminology. In addition to capturing the problem, I will focus on designing my models in such a way that a developer can’t violate a business rule because the code won’t compile. At this point, I would have made illegal states unrepresentable in my code.

I first came across this term while reading Scott Wlashcin‘s work on the terrific F# for Fun and Profit website and it immediately resonated with me. I’ve definitely been bitten before working in a codebase where I wrote some code that compiled but blew up in my face during runtime because the parameter I passed in wasn’t valid for the method I was calling. Wouldn’t it be nice if the compiler told me while I was writing the code that what I was doing wouldn’t work? By thinking a bit more about the models being used and what some of their properties are, we can make this goal achievable.

### Modeling Types

With these goals in mind, when it comes to modeling concepts, I naturally gravitate to types and find that types will fall in one of three categories.

#### The Type Has a Finite Number of Values

If the type has a finite number of valid values, then we can remove error conditions by defining the type to only be one of those possible options. For those from an Object-Oriented background, enums are a great example of modeling these types as you can explicitly set a label for the different values. For those from a Functional background, sum types are a great way to model these choices.

Some examples of such a type include the states in the U.S., the suits for a deck of playing cards, or the months in a year.

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16``` ``````public enum State { Alabama, Alaska, California, Delaware, Florida, Georgia, Tennessee, Wyoming } public enum Suit { Hearts, Clubs, Spades, Diamonds } public enum Months { January, February, March, April, May, June, July, August, September, October, November, December } ``````
 ```1 2 3``` ``````type State = Alabama | Alaska | California | Delaware | Florida | Georgia | Tennesee | Wyoming ``````

#### The Type Has an Infinite Number of Values

For other types, however, there are so many possible valid values that it’s impossible to list all of them. For example, if we were looking at valid house numbers for an address, any positive integer would be valid so good luck on defining every positive number as an enum or sum type.

In these cases, I will leverage built-in primitives to model the concept at first. So in the case of HouseNumber, an integer might be a good enough spot to start. However, if I then find myself writing code that can work on integers, but shouldn’t work on HouseNumbers, then I might wrap a stronger type around the integer (see below).

 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22``` ``````// If the value isn't a major component of the design, we can use a primitive type int houseNumber; // However, if the type is a major concept to the domain at hand, // it makes sense to lift it to its own type public class HouseNumber { public int Value {get;} public StreetNumber(int input) { // validation logic Value = input; } } // The difference between the two approaches is that in the first case, this would work int houseNumber = 400; Math.Sqrt(houseNumber); // But this wouldn't var houseNumber = new HouseNumber(400); Math.Sqrt(houseNumber); // fails to compile with "cannot convert from HouseNumber to double" ``````
 ``` 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15``` ``````// If the value isn't a major component of the design, we can use a primitive type let houseNumber:int; // However, if the type is a major concept to the domain at hand, // it makes sense to lift it to its own type (single case sum type) type HouseNumber = HouseNumber of int // The difference between the two approaches is that in the first case, this would work let houseNumber = 400; Math.Sqrt(houseNumber); // But this wouldn't let houseNumber = HouseNumber 400 Math.Sqrt(houseNumber); // fails to compile with // "This expression was expected to have type 'float' but here has type 'HouseNumber'" ``````

#### The Type Is a Composition of Other Types

As the saying goes, large programs are built by composing a bunch of smaller programs, and types are no different. As we begin to model more complicated types, it’s natural to start thinking about types being composed of other types. For these types, we’ll leverage either objects (if following OO) or records (if following FP).

One way you can determine if you’re needing a composite type like this is if you find yourself using the word and or has when describing the type, then it’s a composition. For example:

An Address has a HouseNumber, it has a StreetName, it has a State.

An Address consists of a HouseNumber and a StreetName and a State

 ```1 2 3 4 5 6``` ``````public class Address { public int HouseNumber {get; set;} public string StreetName {get; set;} public State State {get; set;} } ``````
 ```1 2 3 4 5``` ``````type Address = { houseNumber:int, streetName:string, state:State } ``````

#### Modeling Types

Now that we’ve talked about some different modeling techniques, let’s see how we can apply those rules as we start to model Mars Rover. From the previous post, we were able to derive the following concepts and relationships:

• A Rover has a Location and an Orientation
• Orientation is the Direction that a Rover is facing
• Location is the coordinates that the Rover is located at
• A Command is something that a Rover receives from the User
• A Direction can be North, East, South, or West
• A Command can be Move Forward, Move Backward, Turn Left, Turn Right, or Quit

Yielding the following graph

Given the above rules, we can start taking a look at how to model these in code! We’ll first start with the models that don’t have a dependency, and then build up from there

#### Modeling Direction

From the above requirements, Direction can only be one of four possible values (North, East, South, West). So based on that, it looks like we can leverage the first rule and model Direction like so:

 ```1 2 3 4``` ``````public enum Direction { North, South, East, West } ``````
 `1` ``````type Direction = North | East | South | West ``````

#### Modeling Command

From the above requirements, Command can only be one of five possible values (MoveForward, MoveBackward, TurnLeft, TurnRight, and Quit). Based on that, we can once again leverage the first rule and model Command like so:

 ```1 2 3 4 5 6``` ``````public enum Command { MoveForward, MoveBackward, TurnLeft, TurnRight, Quit } ``````
 ```1 2``` ``````type Command = MoveForward | MoveBackward | TurnLeft | TurnRight | Quit ``````

#### Modeling Location

After talking more with our Subject Matter Expert, a Location is the Coordinate where the Rover is located.

Aha! A new concept!

When we ask additional questions, we find out that a Coordinate refers to the Cartesian Coordinate System and for the problem we’re solving, we can assume that a Coordinate represents two numbers where the first number represents the location from the x-axis and the second number represents the location from the y-axis.

With this new information, our mental model has changed to be the following

Going into further discussion, we find out that both X and Y will be whole numbers for our emulation and that they can be negative. Based on these properties, it sounds like X and Y can be modeled as integers and therefore fall under the second rule.

Given that a Coordinate has to have both an X and Y value, it sounds like Coordinate falls under the third rule and that this concept is a composition of X and Y.

 ```1 2 3 4 5``` ``````public class Coordinate { public int X {get; set;} public int Y {get; set;} } ``````
 `1` ``````type Coordinate = {x:int; y:int} ``````

#### Modeling Orientation

From the above requirements, it seems like Orientation is what we call the Direction that the Rover is facing. Based on that, this sounds like a property that Rover would have.

#### Modeling Rover

Now that we have both the Direction and Coordinate concepts designed, we can start designing Rover. From the requirements, it looks like Rover is a combination of Direction (known as Orientation) and a Coordinate (known as a Location). Based on that, Rover falls under the third rule and looks like the following.

 ```1 2 3 4 5``` ``````public class Rover { public Direction Orientation {get; set;} public Coordinate Location {get; set;} } ``````
 ```1 2 3 4``` ``````type Rover = { orientation:Direction; location:Coordinate; } ``````

### Wrapping Up

In this post, we implemented the basic types needed to solve the Mars Rover kata! We first started by taking a look at the concepts identified earlier and thought about the characteristics of the type which helped guide us to build software that both uses the terms of the problem domain and also prevents us from creating errors by making illegal states unrepresentable. In the next post, we’ll start adding functionality to our application.
